Single Sealed EX Stainless Steel Cable Gland JX8 Series

Single Sealed EX Stainless Steel Cable Gland JX8 Series

Material: SU304 for Body
Seal: High Temperature silicone
Protection Class: Within the clamping range, it can reach to AP66
Temperature Ra
  • Single Sealed EX Stainless Steel Cable Gland JX8 Series
Inquiry
Product Description

Material: SU304 for Body

Seal: High Temperature silicone

Protection Class: Within the clamping range, it can reach to AP66

Temperature Range: Min-40 °C,Max 100 °C, short time to 120°C

Thread Options: Metric, G

Application: Zone 1 hazardous locations and IIA IIB IIC explosive gas atmospheres,

Electrical equipment connections, chemicals, petroleum, various sectors of electricity, light industry, machinery, etc, especially for automatic engineering line installation.

Ex Degreea; Exd II C Gb/Ex e II GB

Ex Degree Certificate: CNE x 14.1625X.

Single Sealed Ex Stainless Steel JX8 - Metric, G Thread
Code AG Thread Cable Range (mm) Armor Braid H (mm) GL (mm) Spanner Size (mm) Std. Pkg (pcs)
Metric G Outer Inner Size Size

JX-8-EXS-12 M16*1.5 3/8’’ Φ6-12 Φ4-10 0.9/1.25 0/0.7 30 15 24 50
JX-8-EXS-16A M20*1.5 1/2’’ Φ10-16 Φ8-13 0.9/1.25 0/0.7 30 15 24 50
JX-8-EXS-16B M22*1.5 1/2’’ Φ10-16 Φ8-13 0.9/1.25 0/0.7 30 15 24 50
JX-8-EXS-16C M24*1.5 1/2’’ Φ14-16 Φ12-16 0.9/1.25 0/0.7 32 15 30 50
JX-8-EXS-18 M25*1.5 3/4’’ 1’’ Φ14-18 Φ12-16 1.25/1.6 0/0.7 35 15 40 50
JX-8-EXS-23 M30*1.5 1’’11/4’’ Φ17-23 Φ15-21 1.6/2.0 0.6/1.2 39 15 46 50
JX-8-EXS-27A M32*1.5 1’’11/4’’ Φ22-27 Φ20-25 1.6/2.0 0.6/1.2 39 15 46 50
JX-8-EXS-27B M36*2.0 1’’11/4’’ Φ22-27 Φ20-25 1.6/2.0 0.6/1.2 39 15 55 50
JX-8-EXS-33A M40*1.5 11/2’’ Φ26-33 Φ24-31 1.6/2.0 0.6/1.2 43 15 55 50
JX-8-EXS-33B M48*2.0 11/2’’ Φ26-33 Φ24-31 1.6/2.0 0.6/1.2 43 15 55 50
JX-8-EXS-41 M50*1.5 11/2’’ 2’’ Φ32-41 Φ27-35 1.6/2.0 0.6/1.2 48 15 65 50
JX-8-EXS-49 M56*2.0 2’’ Φ40-49 Φ35-43 1.6/2.0 0.6/1.2 48 20 65 50
JX-8-EXS-57A M63*1.5 21/2’’ Φ48-57 Φ42-50 1.8/2.5 0.6/1.2 53 20 80 50
JX-8-EXS-57B M64*2.0 21/2’’ Φ48-57 Φ42-50 1.8/2.5 0.6/1.2 53 20 80 50
JX-8-EXS-68 M75*1.5 3’’ Φ54-68 Φ45-58 1.8/2.5 1.0/1.5 58 20 96 50
JX-8-EXS-79 M87*1.5 3’’ Φ67-79 Φ56-67 1.8/2.5 1.0/1.5 64 20 114 20
JX-8-EXS-89 M100*1.5 4’’ Φ78-89 Φ65-75 1.8/2.5 1.0/1.5 70 20 138 10
For NPT Thread
JX-8-EXS-12 M16*1.5 3/8’’ Φ6-12 Φ4-10 0.9/1.25 0/0.7 30 15 24 50
JX-8-EXS-16 M20*1.5 1/2’’ Φ10-16 Φ8-13 0.9/1.25 0/0.7 30 15 24 50
JX-8-EXS-18 M22*1.5 3/4’’ Φ14-18 Φ12-16 0.9/1.25 0/0.7 35 15 40 50
JX-8-EXS-23 M24*1.5 1’’ Φ17-23 Φ15-21 1.6/2.0 0.6/1.2 39 15 46 50
JX-8-EXS-27 M25*1.5 11/4’’ Φ22-27 Φ20-25 1.6/2.0 0.6/1.2 43 15 55 50
JX-8-EXS-33 M30*1.5 11/2’’ Φ26-33 Φ24-31 1.6/2.0 0.6/1.2 43 15 55 50
