Jixiang 90 Degree Elbow Nylon Cable Gland is made of UL-approved Nylon PA66, featuring 90-degree angle for flexible cable routing with IP68 protection. It resists weather, chemicals and mechanical stress, comes with internal ratchet for vibration resistance, self-locking function and strain relief, serving as a high-performance sealing solution for industrial and commercial electrical cable connections.
| Item Name: | 90 degree Elbow Nylon Cable Glands |
| Matetrial | UL approved Nylon PA66(Flammability UL94V-2 or UL94V-0) |
| Washer and Seal | NBR EPDM |
| WorkingTemperature: | Static: -40°C ~ 100°C, temporary to 120°C Dynamic: -20°C ~ 80°C, temporary to 100°C |
| Protection Degree: | IP68 with sealing |
Inquiry Now >>
* Seal & clamp system allows the cord connector to tighten in a circular sequence on the sealing ring to give outstanding strain relief w/o twisting or damaging the cable.
* Nylon material resistant to most common chemicals & solvents.
* Internal Ratchet with Self-Locking feature protects against vibrations
* No disassembly required
PG TYPE
|
Model |
Cable Range (mm) |
Thread Length GL(mm) |
H Height (mm) |
Spanner Size (mm) |
Thread O.D. AG(mm) |
Panel Mounting Hole (mm) |
|
JX-NLWPG9 |
4-8 |
8 |
37 |
19 |
15.2 |
15.2-15.5 |
|
JX-NLWPG11 |
5-10 |
8 |
39 |
22 |
18.6 |
18.6-18.9 |
|
JX-NLWPG13.5 |
6-12 |
9 |
43 |
24 |
20.4 |
20.4-20.7 |
|
JX-NLWPG16 |
10-14 |
10 |
48 |
27 |
22.5 |
22.5-22.8 |
|
JX-NLWPG21 |
13-18 |
11 |
56 |
33 |
28.3 |
28.3-28.6 |
|
JX-NLWPG29 |
18-25 |
11 |
68 |
41/42 |
37 |
37-37.3 |
M TYPE
|
Model |
Cable Range (mm) |
Thread Length GL(mm) |
H Height (mm) |
Spanner Size (mm) |
Thread O.D. AG(mm) |
Panel Mounting Hole (mm) |
|
JX-NLWM16X1.5 |
4-8 |
8 |
37 |
19 |
16 |
16-16.3 |
|
JX-NLWM 18X1.5 |
540 |
8 |
39 |
22 |
18 |
18-16.3 |
|
JX-NLWM20X1.5 |
6-12 |
9 |
43 |
24 |
20 |
20-20.3 |
|
JX-NLWM22X1.5 |
10-14 |
10 |
48 |
27 |
22 |
22-22.3 |
|
JX-NLWM25X1.5 |
1348 |
11 |
56 |
33 |
25 |
25-25.3 |
|
JX-NLWM32X1.5 |
18-25 |
11 |
68 |
41/42 |
32 |
32-32.3 |
