Description

Protection grade: IP68

Temperature resistance: -40°C to 105℃

Storagetemperature: Temperature

Main material: Nylon pa66 (flame retardant)

o-ring material: silicon (environmental protection material)

Applicable cable scope: Φ3-6.5 Φ5-8 Φ7-10

Inquiry Now >>

Product Description

Protection grade: IP68

Temperature resistance: -40°C to 105℃

Storagetemperature: Temperature

Main material: Nylon pa66 (flame retardant)

o-ring material: silicon (environmental protection material)

Applicable cable scope: Φ3-6.5 Φ5-8 Φ7-10

wiring method: Screw crimping

Conductor material: 59-1Brass

Applicable line square number: 0.5~2.5mm2

Test voltage: 1500v

Rated voltage/current: 450v/24a

Flame retardant grade: V0



JX-ZXFSH-F1-2T

Model

MN-01

MN-02

MN-03

Quantity/bag

1

1

1

core

2T

2T

2T

Cable range(mm)

3-6.5

5-8

7-10

Per Pcs weight(g)

70

69.6

69.6

One carton weight(kg)

11.1

11

10.9



Protection Grade: lP68

temperature resistance: -40°℃ to 105°℃

storagetemperature: room temper

main material: nylon PA66 (flame retardant)

o-ring material: silicone (environmental protection material)

applicable cable scope: Φ3-6.5 Φ5-8 Φ7-10

wiring method: screw crimping

Conductor material: 59-1 Brass

Applicable Line Square number: 0.5~2.5mm2

test voltage: 1500V

rated voltage/current: 450V/24A

flame retardant grade: V0

package quantity: 10pcs per bag,24 bags per carton,

                              carton size: 49cm*35cm*23cm

JX-ZXFSH-F1-3T

Model

MN-01

MN-02

MN-03

Quantity/bag

1

1

1

core

3T

3T

3T

Cable range(mm)

3-6.5

5-8

7-10

Per Pcs weight(g)

76

75.2

74.4

One carton weight(kg)

10.6

10.5

10.4

Protection Grade: lP68

temperature resistance: -40°℃ to 105°℃

storagetemperature: room temper

main material: nylon PA66 (flame retardant)

o-ring material: silicone (environmental protection material)

applicable cable scope: Φ3-6.5 Φ5-8 Φ7-10

wiring method: screw crimping

Conductor material: 59-1 Brass

Applicable Line Square number: 0.5~2.5mm2

test voltage: 1500V

rated voltage/current: 450V/24A

flame retardant grade: V0

package quantity: 1pcs per bag,144 bags per carton,

                              carton size: 49cm*35cm*23cm



JX-ZXFSH-F1-4T

Model

MN-01

MN-02

MN-03

Quantity/bag

1

1

1

core

4T

4T

Cable range(mm)

3-6.5

5-8

7-10

Per Pcs weight(g)

77.2

76.4

75.2

One carton weight(kg)

9.3

9.2

9.1

Protection Grade: lP68

temperature resistance: -40°℃ to 105°℃

storagetemperature: room temper

main material: nylon PA66 (flame retardant)

o-ring material: Silicon (environmental protection material)

applicable cable scope: Φ3-6.5 Φ5-8 Φ7-10

wiring method: screw crimping

Conductor material: 59-1 Brass

Applicable Line Square number: 0.5~2.5mm2

test voltage: 1500V

rated voltage/current: 450V/24A

flame retardant grade: V0

package quantity: 1pcs per bag,144 bags per carton,

                              carton size: 49cm*35cm*23cm
