Mini Waterproof Junction Box JX-ZXFSH-F1-2T


Protection grade: IP68

Temperature resistance: -40°C to 105℃

Storagetemperature: Temperature

Main material: Nylon pa66 (flame retardant)

o-ring material: silicon (environmental protection material)

Applicable cable scope: Φ3-6.5 Φ5-8 Φ7-10

Inquiry Now >>

Product Description

Protection grade: IP68

Temperature resistance: -40°C to 105°C

Storage temperature: Room temperature

Main material: Nylon PA66 (flame retardant)

0-ring material:  Silicon (environmental protection material)

Applicable cable scope: Φ3-6.5 Φ5-8 Φ7-10

Wiring method: screw crimping

Conductor material: 59-1 Brass

Applicable line square number: 0.5~2.5mm2

Test voltage: 1500V

Rated voltage/current: 450V/24A

Flame retardant grade: V0

Package quantity: 10pcs per bag, 24 bags per carton, carton size: 49cm* 35cm*23cm

Model MN-01 MN-02 MN-03
Quantity/bag 1 1 1
Core 2T 2T 2T
Cable range(mm) 3-6.5 5-8 7-10
Per Pcs weight (g) 70 69.6 69.6
one carton weight (kg) 11.1 11 10.9
