1: What are the main application fields of explosion-proof cable joints?Answer: Explosion-proof Cable Gland are wid...
View More
Inquiry Now >>
Protection grade: IP68
Temperature resistance: -40°C to 105°C
Storage temperature: Room temperature
Main material: Nylon PA66 (flame retardant)
0-ring material: Silicon (environmental protection material)
Applicable cable scope: Φ3-6.5 Φ5-8 Φ7-10
Wiring method: screw crimping
Conductor material: 59-1 Brass
Applicable line square number: 0.5~2.5mm2
Test voltage: 1500V
Rated voltage/current: 450V/24A
Flame retardant grade: V0
Package quantity: 1pcs per bag, 144 bags per carton, carton size: 49cm* 35cm* 23cm
| Model | MN-01 | MN-02 | MN-03 |
| Quantity/bag | 1 | 1 | 1 |
| Core | 3T | 3T | 3T |
| Cable range(mm) | 3-6.5 | 5-8 | 7-10 |
| Per Pcs weight (g) | 76 | 75.2 | 74.4 |
| one carton weight (kg) | 10.6 | 10.5 | 10.4 |
We are cable gland manufacturer, we have our own workers and terminal block factory.
We have been more than 10 years' Professional terminal block production experience.
We professional produce various types of terminal block:SEK series Screw Terminal Block, SUK series Screw Terminal Block, JF5 series Screw Terminal Block, SN series Screw Terminal Block, ST3 series Spring Terminal Block to clients' needs.
Our factory is located in yueqing city,zhejiang province, China. Our local airport is wenzhou yongqiang airport.
The nearest international airport is shanghai pudong airport.
about 40 minutes by plane from shanghai (4 hours by train)
